摘要：针对 Kubernetes（K8s）集群中高可用 master 节点的 ETCD 挂掉问题，恢复过程包括备份恢复或重新选举新的 ETCD 节点。检查 ETCD 集群状态，确认节点挂掉情况。若存在备份，可恢复 ETCD 数据至备份状态；若无备份，需重新配置健康的 ETCD 节点以恢复集群。确保 Kubernetes 集群的 API 服务可用性，并监控 ETCD 性能以避免再次出现问题。恢复后验证集群状态以确保高可用性和稳定性。
写在前面
- 很常见的集群运维场景，整理分享
- 博文内容为 K8s 集群高可用 master 节点故障如何恢复的过程
- 理解不足小伙伴帮忙指正
不必太纠结于当下，也不必太忧虑未来，当你经历过一些事情的时候，眼前的风景已经和从前不一样了。——村上春树
（图片来源网络，侵删）遇到了什么问题
今天做实验发现 ，集群其中一个 master 节点上的 etcd 和 apiserver 都挂掉了
┌──[root@vms100.liruilongs.github.io]-[~] └─$kubectl get nodes NAME STATUS ROLES AGE VERSION vms100.liruilongs.github.io Ready control-plane 415d v1.25.1 vms101.liruilongs.github.io Ready control-plane 415d v1.25.1 vms102.liruilongs.github.io Ready control-plane 415d v1.25.1 vms103.liruilongs.github.io Ready 415d v1.25.1 vms105.liruilongs.github.io Ready 415d v1.25.1 vms106.liruilongs.github.io Ready 415d v1.25.1 ┌──[root@vms100.liruilongs.github.io]-[~] └─$
vms100.liruilongs.github.io 这个节点 上的 apiserver 和 etcd
（图片来源网络，侵删）┌──[root@vms100.liruilongs.github.io]-[~] └─$kubectl get pod -A -o wide | grep apiserver kube-system kube-apiserver-vms100.liruilongs.github.io 0/1 CrashLoopBackOff 1448 (3m23s ago) 415d 192.168.26.100 vms100.liruilongs.github.io kube-system kube-apiserver-vms101.liruilongs.github.io 1/1 Running 272 (3h18m ago) 415d 192.168.26.101 vms101.liruilongs.github.io kube-system kube-apiserver-vms102.liruilongs.github.io 1/1 Running 246 (3h18m ago) 415d 192.168.26.102 vms102.liruilongs.github.io ┌──[root@vms100.liruilongs.github.io]-[~] └─$kubectl get pod -A -o wide | grep etcd kube-system etcd-vms100.liruilongs.github.io 0/1 CrashLoopBackOff 1244 (3m6s ago) 415d 192.168.26.100 vms100.liruilongs.github.io kube-system etcd-vms101.liruilongs.github.io 1/1 Running 167 (3h18m ago) 415d 192.168.26.101 vms101.liruilongs.github.io kube-system etcd-vms102.liruilongs.github.io 1/1 Running 173 (3h18m ago) 415d 192.168.26.102 vms102.liruilongs.github.io
查看 keepalived 对应的静态Pod运行正常
┌──[root@vms100.liruilongs.github.io]-[~] └─$kubectl get pod -A -o wide | grep keep kube-system keepalived-vms100.liruilongs.github.io 1/1 Running 63 (3h50m ago) 415d 192.168.26.100 vms100.liruilongs.github.io kube-system keepalived-vms101.liruilongs.github.io 1/1 Running 54 (3h51m ago) 415d 192.168.26.101 vms101.liruilongs.github.io kube-system keepalived-vms102.liruilongs.github.io 1/1 Running 60 (3h51m ago) 415d 192.168.26.102 vms102.liruilongs.github.io ┌──[root@vms100.liruilongs.github.io]-[~] └─$
所以可能是 etcd 数据不同步，或者什么原因 导致etcd 挂掉了。因为 每个 master 节点的 apiserver 只和 本节点的 etcd 进行 通信(每个 etcd 的写请求会转发到 etcd 的领导节点)，etcd 挂掉，apiserver 无法提供能力，所以也会挂掉。
通过 etcdctl 可以发现 vms100.liruilongs.github.io 上的 etcd 彻底死掉了
┌──[root@vms100.liruilongs.github.io]-[~] └─$ETCDCTL_API=3 etcdctl --endpoints https://127.0.0.1:2379 \ --cert="/etc/kubernetes/pki/etcd/server.crt" \ --key="/etc/kubernetes/pki/etcd/server.key" \ --cacert="/etc/kubernetes/pki/etcd/ca.crt" \ member list -w table Error: dial tcp 127.0.0.1:2379: connect: connection refused
如何排查
这里我们换一个 etcd 节点 执行 命令
查看 etcd 集群成员
┌──[root@vms100.liruilongs.github.io]-[~] └─$ssh vms101.liruilongs.github.io Last login: Sat Mar 2 09:52:01 2024 from 192.168.26.100 ┌──[root@vms101.liruilongs.github.io]-[~] └─$ETCDCTL_API=3 etcdctl --endpoints https://127.0.0.1:2379 \ --cert="/etc/kubernetes/pki/etcd/server.crt" \ --key="/etc/kubernetes/pki/etcd/server.key" \ --cacert="/etc/kubernetes/pki/etcd/ca.crt" \ member list -w table +------------------+---------+-----------------------------+-----------------------------+-----------------------------+ | ID | STATUS | NAME | PEER ADDRS | CLIENT ADDRS | +------------------+---------+-----------------------------+-----------------------------+-----------------------------+ | ee392e5273e89e2 | started | vms100.liruilongs.github.io | https://192.168.26.100:2380 | https://192.168.26.100:2379 | | 70059e836d19883d | started | vms101.liruilongs.github.io | https://192.168.26.101:2380 | https://192.168.26.101:2379 | | b8cb9f66c2e63b91 | started | vms102.liruilongs.github.io | https://192.168.26.102:2380 | https://192.168.26.102:2379 | +------------------+---------+-----------------------------+-----------------------------+-----------------------------+
查看节点状态
┌──[root@vms101.liruilongs.github.io]-[~] └─$ETCDCTL_API=3 etcdctl --endpoints https://127.0.0.1:2379 \ --cert="/etc/kubernetes/pki/etcd/server.crt" \ --key="/etc/kubernetes/pki/etcd/server.key" \ --cacert="/etc/kubernetes/pki/etcd/ca.crt" \ endpoint status --cluster -w table Failed to get the status of endpoint https://192.168.26.100:2379 (context deadline exceeded) +-----------------------------+------------------+---------+---------+-----------+-----------+------------+ | ENDPOINT | ID | VERSION | DB SIZE | IS LEADER | RAFT TERM | RAFT INDEX | +-----------------------------+------------------+---------+---------+-----------+-----------+------------+ | https://192.168.26.101:2379 | 70059e836d19883d | 3.5.4 | 88 MB | false | 603 | 22208417 | | https://192.168.26.102:2379 | b8cb9f66c2e63b91 | 3.5.4 | 88 MB | true | 603 | 22208417 | +-----------------------------+------------------+---------+---------+-----------+-----------+------------+
确定 ETCD 节点故障
┌──[root@vms101.liruilongs.github.io]-[~] └─$ETCDCTL_API=3 etcdctl --endpoints https://127.0.0.1:2379 \ --cert="/etc/kubernetes/pki/etcd/server.crt" \ --key="/etc/kubernetes/pki/etcd/server.key" \ --cacert="/etc/kubernetes/pki/etcd/ca.crt" \ endpoint health --cluster -w table https://192.168.26.101:2379 is healthy: successfully committed proposal: took = 3.753357ms https://192.168.26.102:2379 is healthy: successfully committed proposal: took = 2.989943ms https://192.168.26.100:2379 is unhealthy: failed to connect: dial tcp 192.168.26.100:2379: connect: connection refused Error: unhealthy cluster
查看 etcd 的容器日志
┌──[root@vms100.liruilongs.github.io]-[~] └─$docker ps -a | grep etcd 0f2f98ebf8c3 a8a176a5d5d6 "etcd --advertise-cl…" 4 minutes ago Exited (2) 4 minutes ago k8s_etcd_etcd-vms100.liruilongs.github.io_kube-system_e8c17bb99f9bd8119cdd769556041e18_1252 a4b39d16a753 registry.aliyuncs.com/google_containers/pause:3.8 "/pause" 4 hours ago Up 4 hours k8s_POD_etcd-vms100.liruilongs.github.io_kube-system_e8c17bb99f9bd8119cdd769556041e18_54 ┌──[root@vms100.liruilongs.github.io]-[~] └─$docker logs 0f2f98ebf8c3 {"level":"info","ts":"2024-03-16T14:46:54.644Z","caller":"etcdmain/etcd.go:73","msg":"Running: ","args":["etcd","--advertise-client-urls=https://192.168.26.100:2379","--cert-file=/etc/kubernetes/pki/etcd/server.crt","--client-cert-auth=true","--data-dir=/var/lib/etcd","--experimental-initial-corrupt-check=true","--experimental-watch-progress-notify-interval=5s","--initial-advertise-peer-urls=https://192.168.26.100:2380","--initial-cluster=vms100.liruilongs.github.io=https://192.168.26.100:2380","--key-file=/etc/kubernetes/pki/etcd/server.key","--listen-client-urls=https://127.0.0.1:2379,https://192.168.26.100:2379","--listen-metrics-urls=http://127.0.0.1:2381","--listen-peer-urls=https://192.168.26.100:2380","--name=vms100.liruilongs.github.io","--peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt","--peer-client-cert-auth=true","--peer-key-file=/etc/kubernetes/pki/etcd/peer.key","--peer-trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt","--snapshot-count=10000","--trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt"]} {"level":"info","ts":"2024-03-16T14:46:54.645Z","caller":"etcdmain/etcd.go:116","msg":"server has been already initialized","data-dir":"/var/lib/etcd","dir-type":"member"} {"level":"info","ts":"2024-03-16T14:46:54.645Z","caller":"embed/etcd.go:131","msg":"configuring peer listeners","listen-peer-urls":["https://192.168.26.100:2380"]} {"level":"info","ts":"2024-03-16T14:46:54.645Z","caller":"embed/etcd.go:479","msg":"starting with peer TLS","tls-info":"cert = /etc/kubernetes/pki/etcd/peer.crt, key = /etc/kubernetes/pki/etcd/peer.key, client-cert=, client-key=, trusted-ca = /etc/kubernetes/pki/etcd/ca.crt, client-cert-auth = true, crl-file = ","cipher-suites":[]} {"level":"info","ts":"2024-03-16T14:46:54.645Z","caller":"embed/etcd.go:139","msg":"configuring client listeners","listen-client-urls":["https://127.0.0.1:2379","https://192.168.26.100:2379"]} {"level":"info","ts":"2024-03-16T14:46:54.645Z","caller":"embed/etcd.go:308","msg":"starting an etcd server","etcd-version":"3.5.4","git-sha":"08407ff76","go-version":"go1.16.15","go-os":"linux","go-arch":"amd64","max-cpu-set":4,"max-cpu-available":4,"member-initialized":true,"name":"vms100.liruilongs.github.io","data-dir":"/var/lib/etcd","wal-dir":"","wal-dir-dedicated":"","member-dir":"/var/lib/etcd/member","force-new-cluster":false,"heartbeat-interval":"100ms","election-timeout":"1s","initial-election-tick-advance":true,"snapshot-count":10000,"snapshot-catchup-entries":5000,"initial-advertise-peer-urls":["https://192.168.26.100:2380"],"listen-peer-urls":["https://192.168.26.100:2380"],"advertise-client-urls":["https://192.168.26.100:2379"],"listen-client-urls":["https://127.0.0.1:2379","https://192.168.26.100:2379"],"listen-metrics-urls":["http://127.0.0.1:2381"],"cors":["*"],"host-whitelist":["*"],"initial-cluster":"","initial-cluster-state":"new","initial-cluster-token":"","quota-size-bytes":2147483648,"pre-vote":true,"initial-corrupt-check":true,"corrupt-check-time-interval":"0s","auto-compaction-mode":"periodic","auto-compaction-retention":"0s","auto-compaction-interval":"0s","discovery-url":"","discovery-proxy":"","downgrade-check-interval":"5s"} panic: freepages: failed to get all reachable pages (page 7744: multiple references) goroutine 109 [running]: go.etcd.io/bbolt.(*DB).freepages.func2(0xc00009c480) /go/pkg/mod/go.etcd.io/bbolt@v1.3.6/db.go:1056 +0xe9 created by go.etcd.io/bbolt.(*DB).freepages /go/pkg/mod/go.etcd.io/bbolt@v1.3.6/db.go:1054 +0x1cd ┌──[root@vms100.liruilongs.github.io]-[~] └─$如何解决
这里最快的办法是重新同步一下这个节点的数据，即把这个故障节点移出 集群，清理完故障节点旧数据在重新添加，操作步骤
- 清理数据目录，移动静态Pod 的yaml 文件：停止故障节点服务，然后删除etcd数据目录。
- 移除故障节点：使用member remove命令剔除错误节点,可以在健康的节点执行命令。
- 添加节点：使用member add命令添加故障节点。
- 重新启动：移动故障节点yaml文件，进行启动
注: 静态Pod 通过加载指定目录的 yaml 文件来调度，kubelet 会定时扫描，删除移动 yaml 文件，静态 Pod 会自动停止,同理。添加 yaml 文件会自动创建静态 Pod
移动静态Pod 的yaml 文件
┌──[root@vms100.liruilongs.github.io]-[~] └─$mv /etc/kubernetes/manifests/{etcd.yaml,kube-apiserver.yaml} /tmp/删除etcd数据目录
┌──[root@vms100.liruilongs.github.io]-[~] └─$rm -rf /var/lib/etcd/*
确认节点 的 etcd 和 apiservier 都已经停止
┌──[root@vms100.liruilongs.github.io]-[~] └─$kubectl get pod -A -o wide | grep apiserver kube-system kube-apiserver-vms101.liruilongs.github.io 1/1 Running 272 (4h15m ago) 415d 192.168.26.101 vms101.liruilongs.github.io kube-system kube-apiserver-vms102.liruilongs.github.io 1/1 Running 246 (4h15m ago) 415d 192.168.26.102 vms102.liruilongs.github.io ┌──[root@vms100.liruilongs.github.io]-[~] └─$kubectl get pod -A -o wide | grep etcd kube-system etcd-vms101.liruilongs.github.io 1/1 Running 167 (4h15m ago) 415d 192.168.26.101 vms101.liruilongs.github.io kube-system etcd-vms102.liruilongs.github.io 1/1 Running 173 (4h15m ago) 415d 192.168.26.102 vms102.liruilongs.github.io ┌──[root@vms100.liruilongs.github.io]-[~] └─$
获取故障节点 ID,下面的操作我们在健康的 etcd 节点执行，或者可以修改 --endpoints
┌──[root@vms101.liruilongs.github.io]-[~] └─$ETCDCTL_API=3 etcdctl --endpoints https://192.168.26.101:2379 --cert="/etc/kubernetes/pki/etcd/server.crt" --key="/etc/kubernetes/pki/etcd/server.key" --cacert="/etc/kubernetes/pki/etcd/ca.crt" member list -w table +------------------+---------+-----------------------------+-----------------------------+-----------------------------+ | ID | STATUS | NAME | PEER ADDRS | CLIENT ADDRS | +------------------+---------+-----------------------------+-----------------------------+-----------------------------+ | ee392e5273e89e2 | started | vms100.liruilongs.github.io | https://192.168.26.100:2380 | https://192.168.26.100:2379 | | 70059e836d19883d | started | vms101.liruilongs.github.io | https://192.168.26.101:2380 | https://192.168.26.101:2379 | | b8cb9f66c2e63b91 | started | vms102.liruilongs.github.io | https://192.168.26.102:2380 | https://192.168.26.102:2379 | +------------------+---------+-----------------------------+-----------------------------+-----------------------------+
移除故障节点
┌──[root@vms101.liruilongs.github.io]-[~] └─$ETCDCTL_API=3 etcdctl --endpoints https://127.0.0.1:2379 --cert="/etc/kubernetes/pki/etcd/server.crt" --key="/etc/kubernetes/pki/etcd/server.key" --cacert="/etc/kubernetes/pki/etcd/ca.crt" member remove ee392e5273e89e2 Member ee392e5273e89e2 removed from cluster 4816f346663d82a7
重新添加
┌──[root@vms101.liruilongs.github.io]-[~] └─$ETCDCTL_API=3 etcdctl --endpoints https://127.0.0.1:2379 --cert="/etc/kubernetes/pki/etcd/server.crt" --key="/etc/kubernetes/pki/etcd/server.key" --cacert="/etc/kubernetes/pki/etcd/ca.crt" member add vms100.liruilongs.github.io --peer-urls=https://192.168.26.100:2380 Member 456f71fdc1ad9917 added to cluster 4816f346663d82a7 ETCD_NAME="vms100.liruilongs.github.io" ETCD_INITIAL_CLUSTER="vms100.liruilongs.github.io=https://192.168.26.100:2380,vms101.liruilongs.github.io=https://192.168.26.101:2380,vms102.liruilongs.github.io=https://192.168.26.102:2380" ETCD_INITIAL_ADVERTISE_PEER_URLS="https://192.168.26.100:2380" ETCD_INITIAL_CLUSTER_STATE="existing"
回到 100 节点机器,移动 Yaml 文件，恢复节点
┌──[root@vms100.liruilongs.github.io]-[~] └─$mv /tmp/{etcd.yaml,kube-apiserver.yaml} /etc/kubernetes/manifests/确认 Pod 状态
┌──[root@vms100.liruilongs.github.io]-[~] └─$kubectl get pod -A -o wide | grep etcd kube-system etcd-vms100.liruilongs.github.io 1/1 Running 0 16s 192.168.26.100 vms100.liruilongs.github.io kube-system etcd-vms101.liruilongs.github.io 1/1 Running 167 (4h32m ago) 415d 192.168.26.101 vms101.liruilongs.github.io kube-system etcd-vms102.liruilongs.github.io 1/1 Running 173 (4h32m ago) 415d 192.168.26.102 vms102.liruilongs.github.io ┌──[root@vms100.liruilongs.github.io]-[~] └─$kubectl get pod -A -o wide | grep apiserver kube-system kube-apiserver-vms100.liruilongs.github.io 1/1 Running 0 24s 192.168.26.100 vms100.liruilongs.github.io kube-system kube-apiserver-vms101.liruilongs.github.io 1/1 Running 272 (4h32m ago) 415d 192.168.26.101 vms101.liruilongs.github.io kube-system kube-apiserver-vms102.liruilongs.github.io 1/1 Running 246 (4h32m ago) 415d 192.168.26.102 vms102.liruilongs.github.io ┌──[root@vms100.liruilongs.github.io]-[~] └─$
查看 etcd 集群状态
┌──[root@vms101.liruilongs.github.io]-[~] └─$ETCDCTL_API=3 etcdctl --endpoints https://127.0.0.1:2379 --cert="/etc/kubernetes/pki/etcd/server.crt" --key="/etc/kubernetes/pki/etcd/server.key" --cacert="/etc/kubernetes/pki/etcd/ca.crt" member list -w table +------------------+-----------+-----------------------------+-----------------------------+-----------------------------+ | ID | STATUS | NAME | PEER ADDRS | CLIENT ADDRS | +------------------+-----------+-----------------------------+-----------------------------+-----------------------------+ | 54952f3b494c0286 | unstarted | | https://192.168.26.100:2380 | | | 70059e836d19883d | started | vms101.liruilongs.github.io | https://192.168.26.101:2380 | https://192.168.26.101:2379 | | b8cb9f66c2e63b91 | started | vms102.liruilongs.github.io | https://192.168.26.102:2380 | https://192.168.26.102:2379 | +------------------+-----------+-----------------------------+-----------------------------+-----------------------------+
这里我们发现 新添加的节点状态不正常，一直是 unstarted
我们在 故障节点执行 etcd 命令。发现故障节点并没有添加到集群，而是作为一个单节点运行。
┌──[root@vms100.liruilongs.github.io]-[~] └─$ETCDCTL_API=3 etcdctl --endpoints https://127.0.0.1:2379 --cert="/etc/kubernetes/pki/etcd/server.crt" --key="/etc/kubernetes/pki/etcd/server.key" --cacert="/etc/kubernetes/pki/etcd/ca.crt" member list -w table +-----------------+---------+-----------------------------+-----------------------------+-----------------------------+ | ID | STATUS | NAME | PEER ADDRS | CLIENT ADDRS | +-----------------+---------+-----------------------------+-----------------------------+-----------------------------+ | ee392e5273e89e2 | started | vms100.liruilongs.github.io | https://192.168.26.100:2380 | https://192.168.26.100:2379 | +-----------------+---------+-----------------------------+-----------------------------+-----------------------------+ ┌──[root@vms100.liruilongs.github.io]-[~] └─$ETCDCTL_API=3 etcdctl --endpoints https://127.0.0.1:2379 --cert="/etc/kubernetes/pki/etcd/server.crt" --key="/etc/kubernetes/pki/etcd/server.key" --cacert="/etc/kubernetes/pki/etcd/ca.crt" endpoint status --cluster -w table +-----------------------------+-----------------+---------+---------+-----------+-----------+------------+ | ENDPOINT | ID | VERSION | DB SIZE | IS LEADER | RAFT TERM | RAFT INDEX | +-----------------------------+-----------------+---------+---------+-----------+-----------+------------+ | https://192.168.26.100:2379 | ee392e5273e89e2 | 3.5.4 | 815 kB | true | 2 | 2261 | +-----------------------------+-----------------+---------+---------+-----------+-----------+------------+ ┌──[root@vms100.liruilongs.github.io]-[~] └─$
也没有同步 当前集群的数据
┌──[root@vms100.liruilongs.github.io]-[~] └─$kubectl get pod -A -o wide --server=https://vms100.liruilongs.github.io:6443 No resources found
遇到这种情况，大部分原因是 某个节点的 etcd配置文件的问题，我的这个问题是 故障节点的 etcd 配置文件，没有集群信息相关配置，所以这里把集群相关配置写入配置
原本的配置文件
┌──[root@vms100.liruilongs.github.io]-[~] └─$cat /etc/kubernetes/manifests/etcd.yaml apiVersion: v1 kind: Pod metadata: annotations: kubeadm.kubernetes.io/etcd.advertise-client-urls: https://192.168.26.100:2379 creationTimestamp: null labels: component: etcd tier: control-plane name: etcd namespace: kube-system spec: containers: - command: - etcd - --advertise-client-urls=https://192.168.26.100:2379 - --cert-file=/etc/kubernetes/pki/etcd/server.crt - --client-cert-auth=true - --data-dir=/var/lib/etcd - --experimental-initial-corrupt-check=true - --experimental-watch-progress-notify-interval=5s - --initial-advertise-peer-urls=https://192.168.26.100:2380 - --initial-cluster=vms100.liruilongs.github.io=https://192.168.26.100:2380 - --key-file=/etc/kubernetes/pki/etcd/server.key - --listen-client-urls=https://127.0.0.1:2379,https://192.168.26.100:2379 - --listen-metrics-urls=http://127.0.0.1:2381 - --listen-peer-urls=https://192.168.26.100:2380 - --name=vms100.liruilongs.github.io - --peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt - --peer-client-cert-auth=true - --peer-key-file=/etc/kubernetes/pki/etcd/peer.key - --peer-trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt - --snapshot-count=10000 - --trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt image: registry.aliyuncs.com/google_containers/etcd:3.5.4-0 。。。。。。。。。。。。。。。。集群信息不全的，添加后的配置文件
┌──[root@vms100.liruilongs.github.io]-[~] └─$cat /etc/kubernetes/manifests/etcd.yaml apiVersion: v1 kind: Pod metadata: annotations: kubeadm.kubernetes.io/etcd.advertise-client-urls: https://192.168.26.100:2379 creationTimestamp: null labels: component: etcd tier: control-plane name: etcd namespace: kube-system spec: containers: - command: - etcd - --advertise-client-urls=https://192.168.26.100:2379 - --cert-file=/etc/kubernetes/pki/etcd/server.crt - --client-cert-auth=true - --data-dir=/var/lib/etcd - --experimental-initial-corrupt-check=true - --experimental-watch-progress-notify-interval=5s - --initial-advertise-peer-urls=https://192.168.26.100:2380 - --initial-cluster=vms100.liruilongs.github.io=https://192.168.26.100:2380,vms101.liruilongs.github.io=https://192.168.26.101:2380 - --initial-cluster-state=existing - --key-file=/etc/kubernetes/pki/etcd/server.key - --listen-client-urls=https://127.0.0.1:2379,https://192.168.26.100:2379 - --listen-metrics-urls=http://127.0.0.1:2381 - --listen-peer-urls=https://192.168.26.100:2380 - --name=vms100.liruilongs.github.io - --peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt - --peer-client-cert-auth=true - --peer-key-file=/etc/kubernetes/pki/etcd/peer.key - --peer-trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt - --snapshot-count=10000 - --trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt然后我们以上面相同的方式从新恢复一次，发现节点直接没有起来
┌──[root@vms100.liruilongs.github.io]-[~] └─$kubectl get pod -A -o wide | grep apiserver kube-system kube-apiserver-vms100.liruilongs.github.io 0/1 CrashLoopBackOff 1 (18s ago) 39s 192.168.26.100 vms100.liruilongs.github.io kube-system kube-apiserver-vms101.liruilongs.github.io 1/1 Running 272 (5h29m ago) 415d 192.168.26.101 vms101.liruilongs.github.io kube-system kube-apiserver-vms102.liruilongs.github.io 1/1 Running 246 (5h29m ago) 415d 192.168.26.102 vms102.liruilongs.github.io ┌──[root@vms100.liruilongs.github.io]-[~] └─$kubectl get pod -A -o wide | grep etcd kube-system etcd-vms100.liruilongs.github.io 0/1 CrashLoopBackOff 3 (21s ago) 53s 192.168.26.100 vms100.liruilongs.github.io kube-system etcd-vms101.liruilongs.github.io 1/1 Running 167 (5h29m ago) 415d 192.168.26.101 vms101.liruilongs.github.io kube-system etcd-vms102.liruilongs.github.io 1/1 Running 173 (5h29m ago) 415d 192.168.26.102 vms102.liruilongs.github.io
查看日志
┌──[root@vms100.liruilongs.github.io]-[~] └─$kubectl logs etcd-vms100.liruilongs.github.io -n kube-system ............................. {"level":"fatal","ts":"2024-03-16T16:25:19.981Z","caller":"etcdmain/etcd.go:204","msg":"discovery failed","error":"error validating peerURLs {ClusterID:4816f346663d82a7 Members:[&{ID:b8cb9f66c2e63b91 RaftAttributes:{PeerURLs:[https://192.168.26.102:2380] IsLearner:false} Attributes:{Name:vms102.liruilongs.github.io ClientURLs:[https://192.168.26.102:2379]}} &{ID:3fbbbed942c51f7b RaftAttributes:{PeerURLs:[https://192.168.26.100:2380] IsLearner:false} Attributes:{Name: ClientURLs:[]}} &{ID:70059e836d19883d RaftAttributes:{PeerURLs:[https://192.168.26.101:2380] IsLearner:false} Attributes:{Name:vms101.liruilongs.github.io ClientURLs:[https://192.168.26.101:2379]}}] RemovedMemberIDs:[]}: member count is unequal","stacktrace":"go.etcd.io/etcd/server/v3/etcdmain.startEtcdOrProxyV2\n\t/go/src/go.etcd.io/etcd/release/etcd/server/etcdmain/etcd.go:204\ngo.etcd.io/etcd/server/v3/etcdmain.Main\n\t/go/src/go.etcd.io/etcd/release/etcd/server/etcdmain/main.go:40\nmain.main\n\t/go/src/go.etcd.io/etcd/release/etcd/server/main.go:32\nruntime.main\n\t/go/gos/go1.16.15/src/runtime/proc.go:225"}根据日志信息，可以看到有用的信息 RemovedMemberIDs:[]}: member count is unequal ,成员数量不相等,在分析日志
{ "level": "info", "ts": "2024-03-16T16:25:19.961Z", "caller": "etcdmain/etcd.go:73", "msg": "Running: ", "args": [ "etcd", "--advertise-client-urls=https://192.168.26.100:2379", "--cert-file=/etc/kubernetes/pki/etcd/server.crt", "--client-cert-auth=true", "--data-dir=/var/lib/etcd", "--experimental-initial-corrupt-check=true", "--experimental-watch-progress-notify-interval=5s", "--initial-advertise-peer-urls=https://192.168.26.100:2380", "--initial-cluster=vms100.liruilongs.github.io=https://192.168.26.100:2380,vms101.liruilongs.github.io=https://192.168.26.101:2380", "--initial-cluster-state=existing", "--key-file=/etc/kubernetes/pki/etcd/server.key", "--listen-client-urls=https://127.0.0.1:2379,https://192.168.26.100:2379", "--listen-metrics-urls=http://127.0.0.1:2381", "--listen-peer-urls=https://192.168.26.100:2380", "--name=vms100.liruilongs.github.io", "--peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt", "--peer-client-cert-auth=true", "--peer-key-file=/etc/kubernetes/pki/etcd/peer.key", "--peer-trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt", "--snapshot-count=10000", "--trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt" ] } .............................................................................. { "level": "warn", "ts": "2024-03-16T16:25:19.981Z", "caller": "etcdmain/etcd.go:146", "msg": "failed to start etcd", "error": "error validating peerURLs {ClusterID:4816f346663d82a7 Members:[&{ID:b8cb9f66c2e63b91 RaftAttributes:{PeerURLs:[https://192.168.26.102:2380] IsLearner:false} Attributes:{Name:vms102.liruilongs.github.io ClientURLs:[https://192.168.26.102:2379]}} &{ID:3fbbbed942c51f7b RaftAttributes:{PeerURLs:[https://192.168.26.100:2380] IsLearner:false} Attributes:{Name: ClientURLs:[]}} &{ID:70059e836d19883d RaftAttributes:{PeerURLs:[https://192.168.26.101:2380] IsLearner:false} Attributes:{Name:vms101.liruilongs.github.io ClientURLs:[https://192.168.26.101:2379]}}] RemovedMemberIDs:[]}: member count is unequal" } { "level": "fatal", "ts": "2024-03-16T16:25:19.981Z", "caller": "etcdmain/etcd.go:204", "msg": "discovery failed", "error": "error validating peerURLs {ClusterID:4816f346663d82a7 Members:[&{ID:b8cb9f66c2e63b91 RaftAttributes:{PeerURLs:[https://192.168.26.102:2380] IsLearner:false} Attributes:{Name:vms102.liruilongs.github.io ClientURLs:[https://192.168.26.102:2379]}} &{ID:3fbbbed942c51f7b RaftAttributes:{PeerURLs:[https://192.168.26.100:2380] IsLearner:false} Attributes:{Name: ClientURLs:[]}} &{ID:70059e836d19883d RaftAttributes:{PeerURLs:[https://192.168.26.101:2380] IsLearner:false} Attributes:{Name:vms101.liruilongs.github.io ClientURLs:[https://192.168.26.101:2379]}}] RemovedMemberIDs:[]}: member count is unequal", "stacktrace": "go.etcd.io/etcd/server/v3/etcdmain.startEtcdOrProxyV2\n\t/go/src/go.etcd.io/etcd/release/etcd/server/etcdmain/etcd.go:204\ngo.etcd.io/etcd/server/v3/etcdmain.Main\n\t/go/src/go.etcd.io/etcd/release/etcd/server/etcdmain/main.go:40\nmain.main\n\t/go/src/go.etcd.io/etcd/release/etcd/server/main.go:32\nruntime.main\n\t/go/gos/go1.16.15/src/runtime/proc.go:225" }可以看到它提示 可能错误与 vms102.liruilongs.github.io 节点相关
然后我们看一下 vms102.liruilongs.github.io 的配置文件
┌──[root@vms102.liruilongs.github.io]-[~] └─$cat /etc/kubernetes/manifests/etcd.yaml apiVersion: v1 kind: Pod metadata: annotations: kubeadm.kubernetes.io/etcd.advertise-client-urls: https://192.168.26.102:2379 creationTimestamp: null labels: component: etcd tier: control-plane name: etcd namespace: kube-system spec: containers: - command: - etcd - --advertise-client-urls=https://192.168.26.102:2379 - --cert-file=/etc/kubernetes/pki/etcd/server.crt - --client-cert-auth=true - --data-dir=/var/lib/etcd - --experimental-initial-corrupt-check=true - --experimental-watch-progress-notify-interval=5s - --initial-advertise-peer-urls=https://192.168.26.102:2380 - --initial-cluster=vms100.liruilongs.github.io=https://192.168.26.100:2380,vms102.liruilongs.github.io=https://192.168.26.102:2380,vms101.liruilongs.github.io=https://192.168.26.101:2380 - --initial-cluster-state=existing - --key-file=/etc/kubernetes/pki/etcd/server.key - --listen-client-urls=https://127.0.0.1:2379,https://192.168.26.102:2379 - --listen-metrics-urls=http://127.0.0.1:2381 - --listen-peer-urls=https://192.168.26.102:2380 - --name=vms102.liruilongs.github.io - --peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt - --peer-client-cert-auth=true - --peer-key-file=/etc/kubernetes/pki/etcd/peer.key - --peer-trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt - --snapshot-count=10000 - --trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt通过配置文件比对，可以发现，之前配置的故障节点的配置任然有问题，少了一个vms102.liruilongs.github.io=https://192.168.26.102:2380节点信息。
"--initial-cluster=vms100.liruilongs.github.io=https://192.168.26.100:2380,vms101.liruilongs.github.io=https://192.168.26.101:2380", "--initial-cluster=vms100.liruilongs.github.io=https://192.168.26.100:2380,vms102.liruilongs.github.io=https://192.168.26.102:2380,vms101.liruilongs.github.io=https://192.168.26.101:2380"
修改完配置，按照上面相同的流程重新恢复节点， 节点恢复
通过 etcdctl 命令检查
┌──[root@vms100.liruilongs.github.io]-[~] └─$ETCDCTL_API=3 etcdctl --endpoints https://127.0.0.1:2379 --cert="/etc/kubernetes/pki/etcd/server.crt" --key="/etc/kubernetes/pki/etcd/server.key" --cacert="/etc/kubernetes/pki/etcd/ca.crt" member list -w table +------------------+---------+-----------------------------+-----------------------------+-----------------------------+ | ID | STATUS | NAME | PEER ADDRS | CLIENT ADDRS | +------------------+---------+-----------------------------+-----------------------------+-----------------------------+ | 70059e836d19883d | started | vms101.liruilongs.github.io | https://192.168.26.101:2380 | https://192.168.26.101:2379 | | ac5f6045dbe477b3 | started | vms100.liruilongs.github.io | https://192.168.26.100:2380 | https://192.168.26.100:2379 | | b8cb9f66c2e63b91 | started | vms102.liruilongs.github.io | https://192.168.26.102:2380 | https://192.168.26.102:2379 | +------------------+---------+-----------------------------+-----------------------------+-----------------------------+
┌──[root@vms100.liruilongs.github.io]-[~] └─$ETCDCTL_API=3 etcdctl --endpoints https://127.0.0.1:2379 --cert="/etc/kubernetes/pki/etcd/server.crt" --key="/etc/kubernetes/pki/etcd/server.key" --cacert="/etc/kubernetes/pki/etcd/ca.crt" endpoint status --cluster -w table +-----------------------------+------------------+---------+---------+-----------+-----------+------------+ | ENDPOINT | ID | VERSION | DB SIZE | IS LEADER | RAFT TERM | RAFT INDEX | +-----------------------------+------------------+---------+---------+-----------+-----------+------------+ | https://192.168.26.101:2379 | 70059e836d19883d | 3.5.4 | 88 MB | false | 603 | 22227327 | | https://192.168.26.100:2379 | ac5f6045dbe477b3 | 3.5.4 | 88 MB | false | 603 | 22227327 | | https://192.168.26.102:2379 | b8cb9f66c2e63b91 | 3.5.4 | 88 MB | true | 603 | 22227327 | +-----------------------------+------------------+---------+---------+-----------+-----------+------------+ ┌──[root@vms100.liruilongs.github.io]-[~] └─$
故障节点恢复，在实际的操作中，添加完节点，我们需要确认故障节点的配置文件是否是正确的配置文件
