摘要：，，本内容主要介绍了Android开发中的视频压缩技术。详细介绍了如何进行视频压缩，包括压缩工具的选择、压缩参数的设置以及压缩过程中的注意事项等。通过学习和实践，开发者可以掌握视频压缩的技巧，优化视频文件大小，节省存储空间，提高应用性能。这对于需要处理大量视频数据的Android应用来说，具有重要的实用价值。
视频压缩是一个有关视频类项目必不可少的环节，选择一个合适且稳定的压缩工具更是领开发者比较头疼的一件事情，网上压缩工具比比皆是，一旦入坑，如果出问题后期出现问题，各种成本更是令人畏惧,这篇文章或许可以让你少走一些“弯路”。
（图片来源网络，侵删）
首先这里的视频压缩使用的是 VideoProcessor 介意者勿扰~,并且是音视频类实战项目长期稳定之后才写的此文章,压缩比基本保持在 7:3 左右。
接下来开始实战使用,以及遇到的问题。
（图片来源网络，侵删）
1.导入依赖
com.github.yellowcath:VideoProcessor:2.4.2
2.调用方法
VideoProcessor.processor(mPresenter)
.input(url)
.outWidth(1600)
.outHeight(1200)
.output(outputUrl)
.bitrate(mBitrate)
.frameRate(10)
.process()
方法介绍
.processor(mPresenter) - mPresenter 传入当前引用 .input(url) - url本地视频地址 .outWidth(1600) - 压缩后的宽度 .outHeight(1200) - 压缩后的高度 .output(outputUrl) - 压缩后的地址 .bitrate(mBitrate) - 比特率 .frameRate(10) - 帧速率
比特率会影响到压缩视频之后的效果，可以动态去设置比特率和帧速率去调整压缩效果
//默认三百万，有数据后拿数据的百分之四十
var mBitrate = 3000000
try {
//拿到视频的比特率
var media = MediaMetadataRetriever()
media.setDataSource(locationVideoUrl)
val extractMetadata =
media.extractMetadata(MediaMetadataRetriever.METADATA_KEY_BITRATE)
Log.e(ContentValues.TAG, "当前视频的大小242412412 比特率->：${extractMetadata}")
if (extractMetadata != null && extractMetadata.isNotEmpty()) {
mBitrate = (extractMetadata.toInt() * 0.4).toInt()
}
} catch (e: Exception) {
e.printStackTrace()
}
以上就是压缩视频的使用步骤
以下是出现的问题
首先上述代码中很明显的错误就是压缩后的宽高是写死的，这样当用户传入不同形状的大小肯定会变形，所以我们可以根据原视频宽高进行压缩
基本我们会去本地拿资源会经过 onActivityResult 回调并且拿到 Intent data
可以通过
public static List obtainMultipleResult(Intent data) {
List result = new ArrayList();
if (data != null) {
result = (List) data.getSerializableExtra(PictureConfig.EXTRA_RESULT_SELECTION);
if (result == null) {
result = new ArrayList();
}
return result;
}
return result;
}
LocalMedia
public class LocalMedia implements Parcelable {
private String path;
private String compressPath;
private String cutPath;
private long duration;
private boolean isChecked;
private boolean isCut;
public int position;
private int num;
private int mimeType;
private String pictureType;
private boolean compressed;
private int width;
private int height;
public String ossUrl;//记录上传成功后的图片地址
public boolean isFail;//新增业务字段 是否是违规
public LocalMedia() {
}
public LocalMedia(String path, long duration, int mimeType, String pictureType) {
this.path = path;
this.duration = duration;
this.mimeType = mimeType;
this.pictureType = pictureType;
}
public LocalMedia(String path, long duration, int mimeType, String pictureType, int width, int height) {
this.path = path;
this.duration = duration;
this.mimeType = mimeType;
this.pictureType = pictureType;
this.width = width;
this.height = height;
}
public LocalMedia(String path, long duration,
boolean isChecked, int position, int num, int mimeType) {
this.path = path;
this.duration = duration;
this.isChecked = isChecked;
this.position = position;
this.num = num;
this.mimeType = mimeType;
}
public String getPictureType() {
if (TextUtils.isEmpty(pictureType)) {
pictureType = "image/jpeg";
}
return pictureType;
}
public void setPictureType(String pictureType) {
this.pictureType = pictureType;
}
public String getPath() {
return path;
}
public void setPath(String path) {
this.path = path;
}
public String getCompressPath() {
return compressPath;
}
public void setCompressPath(String compressPath) {
this.compressPath = compressPath;
}
public String getCutPath() {
return cutPath;
}
public void setCutPath(String cutPath) {
this.cutPath = cutPath;
}
public long getDuration() {
return duration;
}
public void setDuration(long duration) {
this.duration = duration;
}
public boolean isChecked() {
return isChecked;
}
public void setChecked(boolean checked) {
isChecked = checked;
}
public boolean isCut() {
return isCut;
}
public void setCut(boolean cut) {
isCut = cut;
}
public int getPosition() {
return position;
}
public void setPosition(int position) {
this.position = position;
}
public int getNum() {
return num;
}
public void setNum(int num) {
this.num = num;
}
public int getMimeType() {
return mimeType;
}
public void setMimeType(int mimeType) {
this.mimeType = mimeType;
}
public boolean isCompressed() {
return compressed;
}
public void setCompressed(boolean compressed) {
this.compressed = compressed;
}
public int getWidth() {
return width;
}
public void setWidth(int width) {
this.width = width;
}
public int getHeight() {
return height;
}
public void setHeight(int height) {
this.height = height;
}
@Override
public int describeContents() {
return 0;
}
@Override
public void writeToParcel(Parcel dest, int flags) {
dest.writeString(this.path);
dest.writeString(this.compressPath);
dest.writeString(this.cutPath);
dest.writeLong(this.duration);
dest.writeByte(this.isChecked ? (byte) 1 : (byte) 0);
dest.writeByte(this.isCut ? (byte) 1 : (byte) 0);
dest.writeInt(this.position);
dest.writeInt(this.num);
dest.writeInt(this.mimeType);
dest.writeString(this.pictureType);
dest.writeByte(this.compressed ? (byte) 1 : (byte) 0);
dest.writeInt(this.width);
dest.writeInt(this.height);
}
protected LocalMedia(Parcel in) {
this.path = in.readString();
this.compressPath = in.readString();
this.cutPath = in.readString();
this.duration = in.readLong();
this.isChecked = in.readByte() != 0;
this.isCut = in.readByte() != 0;
this.position = in.readInt();
this.num = in.readInt();
this.mimeType = in.readInt();
this.pictureType = in.readString();
this.compressed = in.readByte() != 0;
this.width = in.readInt();
this.height = in.readInt();
}
@Override
public boolean equals(Object o) {
if (this == o) return true;
if (o == null || getClass() != o.getClass()) return false;
LocalMedia that = (LocalMedia) o;
return path != null && path.equals(that.path);
}
@Override
public int hashCode() {
if (path != null) {
return path.hashCode();
} else {
return 0;
}
}
public static final Parcelable.Creator CREATOR = new Parcelable.Creator() {
@Override
public LocalMedia createFromParcel(Parcel source) {
return new LocalMedia(source);
}
@Override
public LocalMedia[] newArray(int size) {
return new LocalMedia[size];
}
};
}
将拿到的data 转成 LocalMedia 的集合，默认取第一个 result.get(0)
此时我们就拿到了LocalMedia 这里面有我们需要的宽、高、时间、本地路径等信息
此时我们就可以将上面代码改成
Int videoWith = 1600
Int videoHeight = 1200
if (videoMedia.width != null && videoMedia.width != 0){
videoWith = videoMedia.width
}
if (videoMedia.height != null && videoMedia.height != 0){
videoHeight = videoMedia.height
}
VideoProcessor.processor(mPresenter)
.input(url)
.outWidth(videoWith )
.outHeight(videoHeight )
.output(outputUrl)
.bitrate(mBitrate)
.frameRate(10)
.process()
以上，视频压缩之后变形的问题就解决了
我们压缩之后会出现一个新的压缩后的路径，如果不及时删除，用户手机上就会多一个压缩之后的文件,会影响用户的使用体验，当我们使用之后要及时去删除压缩后的文件(这里不贴代码了,百度一大堆，如有需要请留言~)
删除的时候，部分机型会报错，此时需要注意了！安卓现在已经不允许对 /0 文件也就是系统默认文件进行操作了,所以我们设置的压缩后的路径不要放在 /0 目录下
可以这样
//压缩视频，使用完后别忘了把压缩后的视频删除掉
val FILENAME_FORMAT = "yyyy-MM-dd-HH-mm-ss-SSS"
var outputUrl =
mPresenter.getExternalFilesDir("").toString() + "/Kome" + SimpleDateFormat(
FILENAME_FORMAT,
Locale.CHINA
).format(System.currentTimeMillis()) + ".mp4"
这样基本都压缩步骤已经完成了，不出意外的话就要发版了，但是发上去之后就会发现部分机型会出现空指针的问题，经排查问题发生在底层源码里面 …processVideo()方法里面报错
可能最新版本已经修复此问题，如果没有可以直接重写 VideoProcessor 类，加一下防护，类似于 默认数据都是原有参数，尽量自己不要乱改
int originWidth = 1600;
if (retriever.extractMetadata(MediaMetadataRetriever.METADATA_KEY_VIDEO_WIDTH) != null){
originWidth = Integer.parseInt(retriever.extractMetadata(MediaMetadataRetriever.METADATA_KEY_VIDEO_WIDTH));
}
最后贴上加防护后的VideoProcessor 代码
import android.annotation.SuppressLint;
import android.annotation.TargetApi;
import android.content.Context;
import android.media.AudioFormat;
import android.media.MediaCodec;
import android.media.MediaCodecInfo;
import android.media.MediaExtractor;
import android.media.MediaFormat;
import android.media.MediaMetadataRetriever;
import android.media.MediaMuxer;
import android.media.MediaRecorder;
import android.net.Uri;
import android.util.Pair;
import org.jetbrains.annotations.NotNull;
import org.jetbrains.annotations.Nullable;
import java.io.File;
import java.io.IOException;
import java.nio.ByteBuffer;
import java.util.ArrayList;
import java.util.List;
import java.util.concurrent.CountDownLatch;
import java.util.concurrent.atomic.AtomicBoolean;
import static com.hw.videoprocessor.util.AudioUtil.getAudioBitrate;
import com.hw.videoprocessor.AudioProcessThread;
import com.hw.videoprocessor.VideoDecodeThread;
import com.hw.videoprocessor.VideoEncodeThread;
import com.hw.videoprocessor.VideoUtil;
import com.hw.videoprocessor.util.AudioFadeUtil;
import com.hw.videoprocessor.util.AudioUtil;
import com.hw.videoprocessor.util.CL;
import com.hw.videoprocessor.util.PcmToWavUtil;
import com.hw.videoprocessor.util.VideoMultiStepProgress;
import com.hw.videoprocessor.util.VideoProgressAve;
import com.hw.videoprocessor.util.VideoProgressListener;
@TargetApi(21)
public class VideoProcessor {
final static String TAG = "VideoProcessor";
final static String OUTPUT_MIME_TYPE = "video/avc";
public static int DEFAULT_FRAME_RATE = 20;
/**
* 只有关键帧距为0的才能方便做逆序
*/
public final static int DEFAULT_I_FRAME_INTERVAL = 1;
public final static int DEFAULT_AAC_BITRATE = 192 * 1000;
/**
* 控制音频合成时，如果输入的音频文件长度不够，是否重复填充
*/
public static boolean AUDIO_MIX_REPEAT = true;
final static int TIMEOUT_USEC = 2500;
public static void scaleVideo(Context context, Uri input, String output,
int outWidth, int outHeight) throws Exception {
processor(context)
.input(input)
.output(output)
.outWidth(outWidth)
.outHeight(outHeight)
.process();
}
public static void cutVideo(Context context, Uri input, String output, int startTimeMs, int endTimeMs) throws Exception {
processor(context)
.input(input)
.output(output)
.startTimeMs(startTimeMs)
.endTimeMs(endTimeMs)
.process();
}
public static void changeVideoSpeed(Context context, Uri input, String output, float speed) throws Exception {
processor(context)
.input(input)
.output(output)
.speed(speed)
.process();
}
/**
* 对视频先检查，如果不是全关键帧，先处理成所有帧都是关键帧，再逆序
*/
public static void reverseVideo(Context context, com.hw.videoprocessor.VideoProcessor.MediaSource input, String output, boolean reverseAudio, @Nullable VideoProgressListener listener) throws Exception {
File tempFile = new File(context.getCacheDir(), System.currentTimeMillis() + ".temp");
File temp2File = new File(context.getCacheDir(), System.currentTimeMillis() + ".temp2");
try {
MediaExtractor extractor = new MediaExtractor();
input.setDataSource(extractor);
int trackIndex = VideoUtil.selectTrack(extractor, false);
extractor.selectTrack(trackIndex);
int keyFrameCount = 0;
int frameCount = 0;
List frameTimeStamps = new ArrayList();
while (true) {
int flags = extractor.getSampleFlags();
if (flags > 0 && (flags & MediaExtractor.SAMPLE_FLAG_SYNC) != 0) {
keyFrameCount++;
}
long sampleTime = extractor.getSampleTime();
if (sampleTime = 0) {
MediaFormat audioTrackFormat = extractor.getTrackFormat(audioIndex);
String audioMimeType = MediaFormat.MIMETYPE_AUDIO_AAC;
int bitrate = getAudioBitrate(audioTrackFormat);
int channelCount = audioTrackFormat.getInteger(MediaFormat.KEY_CHANNEL_COUNT);
int sampleRate = audioTrackFormat.getInteger(MediaFormat.KEY_SAMPLE_RATE);
int maxBufferSize = AudioUtil.getAudioMaxBufferSize(audioTrackFormat);
MediaFormat audioEncodeFormat = MediaFormat.createAudioFormat(audioMimeType, sampleRate, channelCount);//参数对应-> mime type、采样率、声道数
audioEncodeFormat.setInteger(MediaFormat.KEY_BIT_RATE, bitrate);//比特率
audioEncodeFormat.setInteger(MediaFormat.KEY_AAC_PROFILE, MediaCodecInfo.CodecProfileLevel.AACObjectLC);
audioEncodeFormat.setInteger(MediaFormat.KEY_MAX_INPUT_SIZE, maxBufferSize);
if (shouldChangeAudioSpeed) {
if (processor.startTimeMs != null || processor.endTimeMs != null || processor.speed != null) {
long durationUs = audioTrackFormat.getLong(MediaFormat.KEY_DURATION);
if (processor.startTimeMs != null && processor.endTimeMs != null) {
durationUs = (processor.endTimeMs - processor.startTimeMs) * 1000;
}
if (processor.speed != null) {
durationUs /= processor.speed;
}
audioEncodeFormat.setLong(MediaFormat.KEY_DURATION, durationUs);
}
} else {
long videoDurationUs = durationMs * 1000;
long audioDurationUs = audioTrackFormat.getLong(MediaFormat.KEY_DURATION);
if (processor.startTimeMs != null || processor.endTimeMs != null || processor.speed != null) {
if (processor.startTimeMs != null && processor.endTimeMs != null) {
videoDurationUs = (processor.endTimeMs - processor.startTimeMs) * 1000;
}
if (processor.speed != null) {
videoDurationUs /= processor.speed;
}
long avDurationUs = videoDurationUs 0) {
for (int i = videoFrameTimeStamps.size() - 1; i >= 0; i--) {
extractor.seekTo(videoFrameTimeStamps.get(i), MediaExtractor.SEEK_TO_CLOSEST_SYNC);
long sampleTime = extractor.getSampleTime();
if (lastFrameTimeUs == -1) {
lastFrameTimeUs = sampleTime;
}
info.presentationTimeUs = lastFrameTimeUs - sampleTime;
info.size = extractor.readSampleData(buffer, 0);
info.flags = extractor.getSampleFlags();
if (info.size 1 ? 1 : videoProgress;
videoProgress *= 0.7f;
listener.onProgress(videoProgress);
}
}
} else {
while (true) {
long sampleTime = extractor.getSampleTime();
if (lastFrameTimeUs == -1) {
lastFrameTimeUs = sampleTime;
}
info.presentationTimeUs = lastFrameTimeUs - sampleTime;
info.size = extractor.readSampleData(buffer, 0);
info.flags = extractor.getSampleFlags();
if (info.size 1 ? 1 : videoProgress;
videoProgress *= 0.7f;
listener.onProgress(videoProgress);
}
long seekTime = sampleTime - MIN_FRAME_INTERVAL;
if (seekTime = 0; i--) {
extractor.seekTo(audioFrameStamps.get(i), MediaExtractor.SEEK_TO_CLOSEST_SYNC);
long sampleTime = extractor.getSampleTime();
if (lastFrameTimeUs == -1) {
lastFrameTimeUs = sampleTime;
}
info.presentationTimeUs = lastFrameTimeUs - sampleTime;
info.size = extractor.readSampleData(buffer, 0);
info.flags = extractor.getSampleFlags();
if (info.size 1 ? 1 : audioProgress;
audioProgress = 0.7f + audioProgress * 0.3f;
listener.onProgress(audioProgress);
}
}
} else {
extractor.seekTo(0, MediaExtractor.SEEK_TO_CLOSEST_SYNC);
while (true) {
long sampleTime = extractor.getSampleTime();
if (sampleTime == -1) {
break;
}
info.presentationTimeUs = sampleTime;
info.size = extractor.readSampleData(buffer, 0);
info.flags = extractor.getSampleFlags();
if (info.size 1 ? 1 : audioProgress;
audioProgress = 0.7f + audioProgress * 0.3f;
listener.onProgress(audioProgress);
}
extractor.advance();
}
}
}
if (listener != null) {
listener.onProgress(1f);
}
} catch (Exception e) {
CL.e(e);
} finally {
extractor.release();
mediaMuxer.release();
}
}
static List getFrameTimeStampsList(MediaExtractor extractor){
List frameTimeStamps = new ArrayList();
while (true) {
long sampleTime = extractor.getSampleTime();
if (sampleTime 0 || fadeOutSec > 0) {
AudioFadeUtil.audioFade(videoPcmAdjustedFile.getAbsolutePath(), sampleRate, channelCount, faceInSec, fadeOutSec);
}
new PcmToWavUtil(sampleRate, channelConfig, channelCount, AudioFormat.ENCODING_PCM_16BIT).pcmToWav(videoPcmAdjustedFile.getAbsolutePath(), videoWavFile.getAbsolutePath());
final int TIMEOUT_US = 2500;
//重新将速率变化过后的pcm写入
int audioBitrate = getAudioBitrate(audioTrackFormat);
int oriVideoIndex = VideoUtil.selectTrack(oriExtrator, false);
MediaFormat oriVideoFormat = oriExtrator.getTrackFormat(oriVideoIndex);
int rotation = oriVideoFormat.containsKey(MediaFormat.KEY_ROTATION) ? oriVideoFormat.getInteger(MediaFormat.KEY_ROTATION) : 0;
MediaMuxer mediaMuxer = new MediaMuxer(output, MediaMuxer.OutputFormat.MUXER_OUTPUT_MPEG_4);
mediaMuxer.setOrientationHint(rotation);
int muxerVideoIndex = mediaMuxer.addTrack(oriVideoFormat);
int muxerAudioIndex = mediaMuxer.addTrack(audioTrackFormat);
//重新写入音频
mediaMuxer.start();
MediaExtractor pcmExtrator = new MediaExtractor();
pcmExtrator.setDataSource(videoWavFile.getAbsolutePath());
int audioTrack = VideoUtil.selectTrack(pcmExtrator, true);
pcmExtrator.selectTrack(audioTrack);
MediaFormat pcmTrackFormat = pcmExtrator.getTrackFormat(audioTrack);
int maxBufferSize = AudioUtil.getAudioMaxBufferSize(pcmTrackFormat);
ByteBuffer buffer = ByteBuffer.allocateDirect(maxBufferSize);
MediaCodec.BufferInfo info = new MediaCodec.BufferInfo();
MediaFormat encodeFormat = MediaFormat.createAudioFormat(MediaFormat.MIMETYPE_AUDIO_AAC, sampleRate, channelCount);//参数对应-> mime type、采样率、声道数
encodeFormat.setInteger(MediaFormat.KEY_BIT_RATE, audioBitrate);//比特率
encodeFormat.setInteger(MediaFormat.KEY_AAC_PROFILE, MediaCodecInfo.CodecProfileLevel.AACObjectLC);
encodeFormat.setInteger(MediaFormat.KEY_MAX_INPUT_SIZE, maxBufferSize);
MediaCodec encoder = MediaCodec.createEncoderByType(MediaFormat.MIMETYPE_AUDIO_AAC);
encoder.configure(encodeFormat, null, null, MediaCodec.CONFIGURE_FLAG_ENCODE);
encoder.start();
boolean encodeInputDone = false;
boolean encodeDone = false;
long lastAudioFrameTimeUs = -1;
final int AAC_FRAME_TIME_US = 1024 * 1000 * 1000 / sampleRate;
boolean detectTimeError = false;
try {
while (!encodeDone) {
int inputBufferIndex = encoder.dequeueInputBuffer(TIMEOUT_US);
if (!encodeInputDone && inputBufferIndex >= 0) {
long sampleTime = pcmExtrator.getSampleTime();
if (sampleTime = 0) {
oriExtrator.unselectTrack(oriAudioIndex);
}
oriExtrator.selectTrack(oriVideoIndex);
oriExtrator.seekTo(0, MediaExtractor.SEEK_TO_PREVIOUS_SYNC);
maxBufferSize = oriVideoFormat.getInteger(MediaFormat.KEY_MAX_INPUT_SIZE);
int frameRate = oriVideoFormat.containsKey(MediaFormat.KEY_FRAME_RATE) ? oriVideoFormat.getInteger(MediaFormat.KEY_FRAME_RATE) : (int) Math.ceil(VideoUtil.getAveFrameRate(mediaSource));
buffer = ByteBuffer.allocateDirect(maxBufferSize);
final int VIDEO_FRAME_TIME_US = (int) (1000 * 1000f / frameRate);
long lastVideoFrameTimeUs = -1;
detectTimeError = false;
while (true) {
long sampleTimeUs = oriExtrator.getSampleTime();
if (sampleTimeUs == -1) {
break;
}
info.presentationTimeUs = sampleTimeUs;
info.flags = oriExtrator.getSampleFlags();
info.size = oriExtrator.readSampleData(buffer, 0);
if (info.size = 0) {
long s1 = System.currentTimeMillis();
final CountDownLatch latch = new CountDownLatch(2);
//音频转化为PCM
new Thread(new Runnable() {
@Override
public void run() {
try {
AudioUtil.decodeToPCM(videoInput, videoPcmFile.getAbsolutePath(), startTimeUs, endTimeUs);
} catch (IOException e) {
throw new RuntimeException(e);
} finally {
latch.countDown();
}
}
}).start();
final File finalAacPcmFile = aacPcmFile;
new Thread(new Runnable() {
@Override
public void run() {
try {
AudioUtil.decodeToPCM(audioInput, finalAacPcmFile.getAbsolutePath(), 0, aacDurationMs > videoDurationMs ? videoDurationMs * 1000 : aacDurationMs * 1000);
} catch (IOException e) {
throw new RuntimeException(e);
} finally {
latch.countDown();
}
}
}).start();
try {
latch.await();
} catch (InterruptedException e) {
e.printStackTrace();
}
long s2 = System.currentTimeMillis();
//检查两段音频格式是否一致,不一致则统一转换为单声道+44100
Pair resultPair = AudioUtil.checkAndAdjustAudioFormat(videoPcmFile.getAbsolutePath(),
aacPcmFile.getAbsolutePath(),
oriExtrator.getTrackFormat(oriAudioIndex),
audioExtractor.getTrackFormat(aacAudioIndex)
);
channelCount = resultPair.first;
sampleRate = resultPair.second;
audioExtractor.release();
long s3 = System.currentTimeMillis();
//检查音频长度是否需要重复填充
if (AUDIO_MIX_REPEAT) {
aacPcmFile = AudioUtil.checkAndFillPcm(aacPcmFile, aacDurationMs, videoDurationMs);
}
//混合并调整音量
adjustedPcm = new File(cacheDir, "adjusted_" + System.currentTimeMillis() + ".pcm");
AudioUtil.mixPcm(videoPcmFile.getAbsolutePath(), aacPcmFile.getAbsolutePath(), adjustedPcm.getAbsolutePath()
, videoVolume, aacVolume);
wavFile = new File(context.getCacheDir(), adjustedPcm.getName() + ".wav");
long s4 = System.currentTimeMillis();
int channelConfig = AudioFormat.CHANNEL_IN_MONO;
if (channelCount == 2) {
channelConfig = AudioFormat.CHANNEL_IN_STEREO;
}
//淡入淡出
if (fadeInSec != 0 || fadeOutSec != 0) {
AudioFadeUtil.audioFade(adjustedPcm.getAbsolutePath(), sampleRate, channelCount, fadeInSec, fadeOutSec);
}
//PCM转WAV
new PcmToWavUtil(sampleRate, channelConfig, channelCount, AudioFormat.ENCODING_PCM_16BIT).pcmToWav(adjustedPcm.getAbsolutePath(), wavFile.getAbsolutePath());
long s5 = System.currentTimeMillis();
CL.et("hwLog", String.format("decode:%dms,resample:%dms,mix:%dms,fade:%dms", s2 - s1, s3 - s2, s4 - s3, s5 - s4));
MediaFormat oriAudioFormat = oriExtrator.getTrackFormat(oriAudioIndex);
audioBitrate = getAudioBitrate(oriAudioFormat);
oriAudioFormat.setString(MediaFormat.KEY_MIME, MediaFormat.MIMETYPE_AUDIO_AAC);
AudioUtil.checkCsd(oriAudioFormat,
MediaCodecInfo.CodecProfileLevel.AACObjectLC,
sampleRate,
channelCount
);
muxerAudioIndex = mediaMuxer.addTrack(oriAudioFormat);
} else {
AudioUtil.decodeToPCM(audioInput, aacPcmFile.getAbsolutePath(), 0,
aacDurationMs > videoDurationMs ? videoDurationMs * 1000 : aacDurationMs * 1000);
MediaFormat audioTrackFormat = audioExtractor.getTrackFormat(aacAudioIndex);
audioBitrate = getAudioBitrate(audioTrackFormat);
channelCount = audioTrackFormat.containsKey(MediaFormat.KEY_CHANNEL_COUNT) ?
audioTrackFormat.getInteger(MediaFormat.KEY_CHANNEL_COUNT) : 1;
sampleRate = audioTrackFormat.containsKey(MediaFormat.KEY_SAMPLE_RATE) ?
audioTrackFormat.getInteger(MediaFormat.KEY_SAMPLE_RATE) : 44100;
int channelConfig = AudioFormat.CHANNEL_IN_MONO;
if (channelCount == 2) {
channelConfig = AudioFormat.CHANNEL_IN_STEREO;
}
AudioUtil.checkCsd(audioTrackFormat,
MediaCodecInfo.CodecProfileLevel.AACObjectLC,
sampleRate,
channelCount);
audioTrackFormat.setString(MediaFormat.KEY_MIME, MediaFormat.MIMETYPE_AUDIO_AAC);
muxerAudioIndex = mediaMuxer.addTrack(audioTrackFormat);
sampleRate = audioTrackFormat.getInteger(MediaFormat.KEY_SAMPLE_RATE);
channelCount = audioTrackFormat.containsKey(MediaFormat.KEY_CHANNEL_COUNT) ? audioTrackFormat.getInteger(MediaFormat.KEY_CHANNEL_COUNT) : 1;
if (channelCount > 2) {
File tempFile = new File(aacPcmFile + ".channel");
AudioUtil.stereoToMonoSimple(aacPcmFile.getAbsolutePath(), tempFile.getAbsolutePath(), channelCount);
channelCount = 1;
aacPcmFile.delete();
aacPcmFile = tempFile;
}
if (aacVolume != 50) {
adjustedPcm = new File(cacheDir, "adjusted_" + System.currentTimeMillis() + ".pcm");
AudioUtil.adjustPcmVolume(aacPcmFile.getAbsolutePath(), adjustedPcm.getAbsolutePath(), aacVolume);
} else {
adjustedPcm = aacPcmFile;
}
channelConfig = AudioFormat.CHANNEL_IN_MONO;
if (channelCount == 2) {
channelConfig = AudioFormat.CHANNEL_IN_STEREO;
}
wavFile = new File(context.getCacheDir(), adjustedPcm.getName() + ".wav");
//淡入淡出
if (fadeInSec != 0 || fadeOutSec != 0) {
AudioFadeUtil.audioFade(adjustedPcm.getAbsolutePath(), sampleRate, channelCount, fadeInSec, fadeOutSec);
}
//PCM转WAV
new PcmToWavUtil(sampleRate, channelConfig, channelCount, AudioFormat.ENCODING_PCM_16BIT).pcmToWav(adjustedPcm.getAbsolutePath(), wavFile.getAbsolutePath());
}
//重新写入音频
mediaMuxer.start();
MediaExtractor pcmExtrator = new MediaExtractor();
pcmExtrator.setDataSource(wavFile.getAbsolutePath());
int audioTrack = VideoUtil.selectTrack(pcmExtrator, true);
pcmExtrator.selectTrack(audioTrack);
MediaFormat pcmTrackFormat = pcmExtrator.getTrackFormat(audioTrack);
int maxBufferSize = AudioUtil.getAudioMaxBufferSize(pcmTrackFormat);
ByteBuffer buffer = ByteBuffer.allocateDirect(maxBufferSize);
MediaCodec.BufferInfo info = new MediaCodec.BufferInfo();
MediaFormat encodeFormat = MediaFormat.createAudioFormat(MediaFormat.MIMETYPE_AUDIO_AAC, sampleRate, channelCount);//参数对应-> mime type、采样率、声道数
encodeFormat.setInteger(MediaFormat.KEY_BIT_RATE, audioBitrate);//比特率
encodeFormat.setInteger(MediaFormat.KEY_AAC_PROFILE, MediaCodecInfo.CodecProfileLevel.AACObjectLC);
encodeFormat.setInteger(MediaFormat.KEY_MAX_INPUT_SIZE, maxBufferSize);
MediaCodec encoder = MediaCodec.createEncoderByType(MediaFormat.MIMETYPE_AUDIO_AAC);
encoder.configure(encodeFormat, null, null, MediaCodec.CONFIGURE_FLAG_ENCODE);
encoder.start();
boolean encodeInputDone = false;
boolean encodeDone = false;
long lastAudioFrameTimeUs = -1;
final int AAC_FRAME_TIME_US = 1024 * 1000 * 1000 / sampleRate;
boolean detectTimeError = false;
try {
while (!encodeDone) {
int inputBufferIndex = encoder.dequeueInputBuffer(TIMEOUT_US);
if (!encodeInputDone && inputBufferIndex >= 0) {
long sampleTime = pcmExtrator.getSampleTime();
if (sampleTime = 0) {
oriExtrator.unselectTrack(oriAudioIndex);
}
oriExtrator.selectTrack(oriVideoIndex);
oriExtrator.seekTo(startTimeUs, MediaExtractor.SEEK_TO_PREVIOUS_SYNC);
maxBufferSize = oriVideoFormat.getInteger(MediaFormat.KEY_MAX_INPUT_SIZE);
int frameRate = oriVideoFormat.containsKey(MediaFormat.KEY_FRAME_RATE) ? oriVideoFormat.getInteger(MediaFormat.KEY_FRAME_RATE) : (int) Math.ceil(VideoUtil.getAveFrameRate(videoInput));
buffer = ByteBuffer.allocateDirect(maxBufferSize);
final int VIDEO_FRAME_TIME_US = (int) (1000 * 1000f / frameRate);
long lastVideoFrameTimeUs = -1;
detectTimeError = false;
while (true) {
long sampleTimeUs = oriExtrator.getSampleTime();
if (sampleTimeUs == -1) {
break;
}
if (sampleTimeUs endTimeUs) {
break;
}
info.presentationTimeUs = sampleTimeUs - startTimeUs;
info.flags = oriExtrator.getSampleFlags();
info.size = oriExtrator.readSampleData(buffer, 0);
if (info.size
文章版权声明：除非注明，否则均为VPS857原创文章，转载或复制请以超链接形式并注明出处。
还没有评论，来说两句吧...
