Android system — 链接器命名空间共享库配置方法

• 1. 应用进程
• • 1.1 应用进程类加载器的命名空间初始化
  • • 1.1.1 OpenNativeLibrary
    • 1.1.2 LibraryNamespaces::Create
    • 1.2 配置共享库位置
    • 2. native进程
    • • 2.1 native 命名空间配置初始化
      • • 2.1.1 android_namespace_t::is_accessible
        • 2.1.2 init_default_namespaces
        • 2.2 配置共享库位置

          1. 应用进程

          1.1 应用进程类加载器的命名空间初始化

            在应用程序对应的可执行文件app_process根据/linkerconfig/ld.config.txt配置文件初始化命名空间之后，每当应用程序创建一个类加载器classloader并调用System.loadLibrary加载so库时都会创建一个与此类加载器对应的命名空间。从源码角度分析一下这个过程，System.loadLibrary函数最后会调用OpenNativeLibrary函数。


          （图片来源网络，侵删）

          1.1.1 OpenNativeLibrary

          System.loadLibrary()-->nativeLoad()-->Runtime.c::Runtime_nativeLoad()-->JVM_NativeLoad()-->Openjdkjvm.cc::JVM_NativeLoad()-->java_vm_ext.cc::LoadNativeLibrary()-->native_loader.cpp::OpenNativeLibrary() 也就是java层的System.loadLibrary()最终会调用libnativeloader.so的OpenNativeLibrary函数。

          • OpenNativeLibrary先判断classloader类加载器是否为空，如果为空直接调用android_dlopen_ext加载库文件
          • 如果判断classloader类加载器不为空，并且classloader类加载器没有对应的命名空间（第一次调用System.loadLibrary)就调用LibraryNamespaces::Create创建新的命名空间。

            void* OpenNativeLibrary(JNIEnv* env, int32_t target_sdk_version, const char* path,
                                    jobject class_loader, const char* caller_location, jstring library_path,
                                    bool* needs_native_bridge, char** error_msg) {
            #if defined(ART_TARGET_ANDROID)
              UNUSED(target_sdk_version);
              if (class_loader == nullptr) { //如果类加载器为空直接调用android_dlopen_ext加载库文件
                *needs_native_bridge = false;
                if (caller_location != nullptr) {
                  android_namespace_t* boot_namespace = FindExportedNamespace(caller_location);
                  if (boot_namespace != nullptr) {
                    const android_dlextinfo dlextinfo = {
                        .flags = ANDROID_DLEXT_USE_NAMESPACE,
                        .library_namespace = boot_namespace,
                    };
                    void* handle = android_dlopen_ext(path, RTLD_NOW, &dlextinfo);
                    if (handle == nullptr) {
                      *error_msg = strdup(dlerror());
                    }
                    return handle;
                  }
                }
                // Check if the library is in NATIVELOADER_DEFAULT_NAMESPACE_LIBS and should
                // be loaded from the kNativeloaderExtraLibs namespace.
                {
                  Result handle = TryLoadNativeloaderExtraLib(path);
                  if (!handle.ok()) {
                    *error_msg = strdup(handle.error().message().c_str());
                    return nullptr;
                  }
                  if (handle.value() != nullptr) {
                    return handle.value();
                  }
                }
                // Fall back to the system namespace. This happens for preloaded JNI
                // libraries in the zygote.
                // TODO(b/185833744): Investigate if this should fall back to the app main
                // namespace (aka anonymous namespace) instead.
                void* handle = OpenSystemLibrary(path, RTLD_NOW);
                if (handle == nullptr) {
                  *error_msg = strdup(dlerror());
                }
                return handle;
              }
              std::lock_guard guard(g_namespaces_mutex);
              NativeLoaderNamespace* ns;
              if ((ns = g_namespaces->FindNamespaceByClassLoader(env, class_loader)) == nullptr) { //如果类加载器不为空，且类加载器没有对应的命名空间就新创建一个
                // This is the case where the classloader was not created by ApplicationLoaders
                // In this case we create an isolated not-shared namespace for it.
                Result isolated_ns =
                    CreateClassLoaderNamespaceLocked(env,
                                                     target_sdk_version,
                                                     class_loader,
                                                     /*is_shared=*/false,
                                                     /*dex_path=*/nullptr,
                                                     library_path,
                                                     /*permitted_path=*/nullptr,
                                                     /*uses_library_list=*/nullptr);
                if (!isolated_ns.ok()) {
                  *error_msg = strdup(isolated_ns.error().message().c_str());
                  return nullptr;
                } else {
                  ns = *isolated_ns;
                }
              }
              return OpenNativeLibraryInNamespace(ns, path, needs_native_bridge, error_msg);


            在CreateClassLoaderNamespaceLocked中我们可以看到调用了LibraryNamespaces::Create创建新的命名空间


            （图片来源网络，侵删）

            Result CreateClassLoaderNamespaceLocked(JNIEnv* env,
                             int32_t target_sdk_version,
                             jobject class_loader,
                             bool is_shared,
                             jstring dex_path,
                             jstring library_path,
                             jstring permitted_path,
                             jstring uses_library_list)
                REQUIRES(g_namespaces_mutex) {
              Result ns = g_namespaces->Create(env,
                        target_sdk_version,
                        class_loader,
                        is_shared,
                        dex_path,
                        library_path,
                        permitted_path,
                        uses_library_list);
              if (!ns.ok()) {
                return ns;
              }
              Result linked = CreateNativeloaderDefaultNamespaceLibsLink(*ns.value());
              if (!linked.ok()) {
                return linked.error();
              }
              return ns;
            }


            1.1.2 LibraryNamespaces::Create

            • 先调用android_create_namespace创建一个clns命名空间
            • 调用android_linker_namespace设置新创建的命名空间链接到system、APEX和vendor等命名空间
            • 设置链接到system、APEX等命名空间的共享库

              Result LibraryNamespaces::Create(JNIEnv* env, uint32_t target_sdk_version,
                        jobject class_loader, bool is_shared,
                        jstring dex_path_j,
                        jstring java_library_path,
                        jstring java_permitted_path,
                        jstring uses_library_list) {
                std::string library_path;  // empty string by default.
                std::string dex_path;
                ......
                // Create the app namespace
                NativeLoaderNamespace* parent_ns = FindParentNamespaceByClassLoader(env, class_loader);
                // Heuristic: the first classloader with non-empty library_path is assumed to
                // be the main classloader for app
                // TODO(b/139178525) remove this heuristic by determining this in LoadedApk (or its
                // friends) and then passing it down to here.
                bool is_main_classloader = app_main_namespace_ == nullptr && !library_path.empty();
                // Policy: the namespace for the main classloader is also used as the
                // anonymous namespace.
                bool also_used_as_anonymous = is_main_classloader;
                // Note: this function is executed with g_namespaces_mutex held, thus no
                // racing here.
                //创建命名空间，namespace_name为kClassloaderNamespaceName = "clns"
                auto app_ns = NativeLoaderNamespace::Create(
                    namespace_name, library_path, permitted_path, parent_ns, is_shared,
                    target_sdk_version IsBridged();
                auto system_ns = NativeLoaderNamespace::GetSystemNamespace(is_bridged);
                if (!system_ns.ok()) {
                  return system_ns.error();
                }
                // 新创建的命名空间链接到system，共享库设置为system_exposed_libraries
                auto linked = app_ns->Link(&system_ns.value(), system_exposed_libraries);
                if (!linked.ok()) {
                  return linked.error();
                }
                for (const auto&[apex_ns_name, public_libs] : apex_public_libraries()) {
                  auto ns = NativeLoaderNamespace::GetExportedNamespace(apex_ns_name, is_bridged);
                  // Even if APEX namespace is visible, it may not be available to bridged.
                  if (ns.ok()) {
                    // 新创建的命名空间链接到APEX，共享库设置为public_libs
                    linked = app_ns->Link(&ns.value(), public_libs);
                    if (!linked.ok()) {
                      return linked.error();
                    }
                  }
                }
                // Give access to VNDK-SP libraries from the 'vndk' namespace for unbundled vendor apps.
                if (unbundled_app_origin == APK_ORIGIN_VENDOR && !vndksp_libraries_vendor().empty()) {
                  auto vndk_ns = NativeLoaderNamespace::GetExportedNamespace(kVndkNamespaceName, is_bridged);
                  if (vndk_ns.ok()) {
                    // 新创建的命名空间链接到vndk，共享库设置为vndksp_libraries_vendor()
                    linked = app_ns->Link(&vndk_ns.value(), vndksp_libraries_vendor());
                    if (!linked.ok()) {
                      return linked.error();
                    }
                  }
                }
                // Give access to VNDK-SP libraries from the 'vndk_product' namespace for unbundled product apps.
                if (unbundled_app_origin == APK_ORIGIN_PRODUCT && !vndksp_libraries_product().empty()) {
                  auto vndk_ns = NativeLoaderNamespace::GetExportedNamespace(kVndkProductNamespaceName, is_bridged);
                  if (vndk_ns.ok()) {
                    linked = app_ns->Link(&vndk_ns.value(), vndksp_libraries_product());
                    if (!linked.ok()) {
                      return linked.error();
                    }
                  }
                }
                for (const std::string& each_jar_path : android::base::Split(dex_path, ":")) {
                  auto apex_ns_name = FindApexNamespaceName(each_jar_path);
                  if (apex_ns_name.ok()) {
                    const auto& jni_libs = apex_jni_libraries(*apex_ns_name);
                    if (jni_libs != "") {
                      auto apex_ns = NativeLoaderNamespace::GetExportedNamespace(*apex_ns_name, is_bridged);
                      if (apex_ns.ok()) {
                        linked = app_ns->Link(&apex_ns.value(), jni_libs);
                        if (!linked.ok()) {
                          return linked.error();
                        }
                      }
                    }
                  }
                }
                auto vendor_libs = filter_public_libraries(target_sdk_version, uses_libraries,
                                                           vendor_public_libraries());
                if (!vendor_libs.empty()) {
                  auto vendor_ns = NativeLoaderNamespace::GetExportedNamespace(kVendorNamespaceName, is_bridged);
                  // when vendor_ns is not configured, link to the system namespace
                  auto target_ns = vendor_ns.ok() ? vendor_ns : system_ns;
                  if (target_ns.ok()) {
                    linked = app_ns->Link(&target_ns.value(), vendor_libs);
                    if (!linked.ok()) {
                      return linked.error();
                    }
                  }
                }
                auto product_libs = filter_public_libraries(target_sdk_version, uses_libraries,
                                                            product_public_libraries());
                if (!product_libs.empty()) {
                  auto target_ns = system_ns;
                  if (is_product_vndk_version_defined()) {
                    // If ro.product.vndk.version is defined, product namespace provides the product libraries.
                    target_ns = NativeLoaderNamespace::GetExportedNamespace(kProductNamespaceName, is_bridged);
                  }
                  if (target_ns.ok()) {
                    linked = app_ns->Link(&target_ns.value(), product_libs);
                    if (!linked.ok()) {
                      return linked.error();
                    }
                  } else {
                    // The linkerconfig must have a problem on defining the product namespace in the system
                    // section. Skip linking product namespace. This will not affect most of the apps. Only the
                    // apps that requires the product public libraries will fail.
                    ALOGW("Namespace for product libs not found: %s", target_ns.error().message().c_str());
                  }
                }
                auto& emplaced = namespaces_.emplace_back(
                    std::make_pair(env->NewWeakGlobalRef(class_loader), *app_ns));
                if (is_main_classloader) {
                  app_main_namespace_ = &emplaced.second;
                }
                return &emplaced.second;
              }


              1.2 配置共享库位置

              通过上面的代码跟踪我们会发现，其实在Android 11后，应用进程共享库的配置位置都在public_libraries.cpp中

              // art/libnativeloader/public_libraries.cpp
              namespace {
              constexpr const char* kDefaultPublicLibrariesFile = "/etc/public.libraries.txt";
              constexpr const char* kExtendedPublicLibrariesFilePrefix = "public.libraries-";
              constexpr const char* kExtendedPublicLibrariesFileSuffix = ".txt";
              constexpr const char* kApexLibrariesConfigFile = "/linkerconfig/apex.libraries.config.txt";
              constexpr const char* kVendorPublicLibrariesFile = "/vendor/etc/public.libraries.txt";
              constexpr const char* kLlndkLibrariesFile = "/apex/com.android.vndk.v{}/etc/llndk.libraries.{}.txt";
              constexpr const char* kVndkLibrariesFile = "/apex/com.android.vndk.v{}/etc/vndksp.libraries.{}.txt";


              只要在命名空间对应的配置文件中加上自己需要的共享库即可

              2. native进程

              2.1 native 命名空间配置初始化

              native进程的so库是直接通过dlopen打开的，而其对应的命名空间也是直接通过linker进行判断的，并没有调用到libnativeloader.so，因此native进程的配置方式也与应用进程不同

              2.1.1 android_namespace_t::is_accessible

              前一篇Android system — 链接器命名空间（linker namespace）源码分析 介绍了dlopen时会通过is_accessible进行权限判断

              // bionic/linker/linker_namespaces.cpp
              // Given an absolute path, can this library be loaded into this namespace?
              bool android_namespace_t::is_accessible(const std::string& file) {
                //判断命名空间的is_isolated_，即是否为严格隔离，如果不是则权限检查通过。
                if (!is_isolated_) {
                  return true;
                }
                //判断是否在允许名单中
                if (!allowed_libs_.empty()) {
                  const char *lib_name = basename(file.c_str());
                  if (std::find(allowed_libs_.begin(), allowed_libs_.end(), lib_name) == allowed_libs_.end()) {
                    return false;
                  }
                }
                //判断是否在ld_library_paths中（LD_LIBRARY_PATH设置）
                for (const auto& dir : ld_library_paths_) {
                  if (file_is_in_dir(file, dir)) {
                    return true;
                  }
                }
                //判断是否在default_library_paths中
                for (const auto& dir : default_library_paths_) {
                  if (file_is_in_dir(file, dir)) {
                    return true;
                  }
                }
                //判断是否在特权路径permitted_paths中
                for (const auto& dir : permitted_paths_) {
                  if (file_is_under_dir(file, dir)) {
                    return true;
                  }
                }
                return false;
              }


              我们可以看到这里有个allowed_libs_，我们跟踪代码可以发现linker_namespaces.h中有set_allowed_libs接口

              // bionic/linker/linker_namespaces.h
                const std::vector& get_allowed_libs() const { return allowed_libs_; }
                void set_allowed_libs(std::vector&& allowed_libs) {
                  allowed_libs_ = std::move(allowed_libs);
                }
                void set_allowed_libs(const std::vector& allowed_libs) {
                  allowed_libs_ = allowed_libs;
                }


              2.1.2 init_default_namespaces

              通过这个思路我们发现调用其实在init_default_namespaces

              • 初始化default命名空间
              • 初始化vndk等其他命名空间
              • 在命名空间之间建立链接

                std::vector init_default_namespaces(const char* executable_path) {
                  g_default_namespace.set_name("(default)");
                  soinfo* somain = solist_get_somain();
                  const char *interp = phdr_table_get_interpreter_name(somain->phdr, somain->phnum,
                        somain->load_bias);
                  const char* bname = (interp != nullptr) ? basename(interp) : nullptr;
                  g_is_asan = bname != nullptr &&
                              (strcmp(bname, "linker_asan") == 0 ||
                               strcmp(bname, "linker_asan64") == 0);
                  const Config* config = nullptr;
                  {
                    std::string ld_config_file_path = get_ld_config_file_path(executable_path);
                    INFO("[ Reading linker config \"%s\" ]", ld_config_file_path.c_str());
                    ScopedTrace trace(("linker config " + ld_config_file_path).c_str());
                    std::string error_msg;
                    if (!Config::read_binary_config(ld_config_file_path.c_str(), executable_path, g_is_asan,
                                                    &config, &error_msg)) {
                      if (!error_msg.empty()) {
                        DL_WARN("Warning: couldn't read '%s' for '%s' (using default configuration instead): %s",
                                ld_config_file_path.c_str(), executable_path, error_msg.c_str());
                      }
                      config = nullptr;
                    }
                  }
                  if (config == nullptr) {
                    return init_default_namespace_no_config(g_is_asan);
                  }
                  const auto& namespace_configs = config->namespace_configs();
                  std::unordered_map namespaces;
                  // 1. Initialize default namespace
                  const NamespaceConfig* default_ns_config = config->default_namespace_config();
                  g_default_namespace.set_isolated(default_ns_config->isolated());
                  g_default_namespace.set_default_library_paths(default_ns_config->search_paths());
                  g_default_namespace.set_permitted_paths(default_ns_config->permitted_paths());
                  namespaces[default_ns_config->name()] = &g_default_namespace;
                  if (default_ns_config->visible()) {
                    g_exported_namespaces[default_ns_config->name()] = &g_default_namespace;
                  }
                  // 2. Initialize other namespaces
                  for (auto& ns_config : namespace_configs) {
                    if (namespaces.find(ns_config->name()) != namespaces.end()) {
                      continue;
                    }
                    android_namespace_t* ns = new (g_namespace_allocator.alloc()) android_namespace_t();
                    ns->set_name(ns_config->name());
                    ns->set_isolated(ns_config->isolated());
                    ns->set_default_library_paths(ns_config->search_paths());
                    ns->set_permitted_paths(ns_config->permitted_paths());
                    ns->set_allowed_libs(ns_config->allowed_libs());
                    namespaces[ns_config->name()] = ns;
                    if (ns_config->visible()) {
                      g_exported_namespaces[ns_config->name()] = ns;
                    }
                  }
                  // 3. Establish links between namespaces
                  for (auto& ns_config : namespace_configs) {
                    auto it_from = namespaces.find(ns_config->name());
                    CHECK(it_from != namespaces.end());
                    android_namespace_t* namespace_from = it_from->second;
                    for (const NamespaceLinkConfig& ns_link : ns_config->links()) {
                      auto it_to = namespaces.find(ns_link.ns_name());
                      CHECK(it_to != namespaces.end());
                      android_namespace_t* namespace_to = it_to->second;
                      if (ns_link.allow_all_shared_libs()) {
                        link_namespaces_all_libs(namespace_from, namespace_to);
                      } else {
                        link_namespaces(namespace_from, namespace_to, ns_link.shared_libs().c_str());
                      }
                    }
                  }
                  // we can no longer rely on the fact that libdl.so is part of default namespace
                  // this is why we want to add ld-android.so to all namespaces from ld.config.txt
                  soinfo* ld_android_so = solist_get_head();
                  // we also need vdso to be available for all namespaces (if present)
                  soinfo* vdso = solist_get_vdso();
                  for (auto it : namespaces) {
                    if (it.second != &g_default_namespace) {
                      it.second->add_soinfo(ld_android_so);
                      if (vdso != nullptr) {
                        it.second->add_soinfo(vdso);
                      }
                      // somain and ld_preloads are added to these namespaces after LD_PRELOAD libs are linked
                    }
                  }
                  set_application_target_sdk_version(config->target_sdk_version());
                  std::vector created_namespaces;
                  created_namespaces.reserve(namespaces.size());
                  for (const auto& kv : namespaces) {
                    created_namespaces.push_back(kv.second);
                  }
                  return created_namespaces;
                }
                }


                这里面我们发现配置文件是通过读取配置文件进行配置的，配置文件ld_config_file_path在Android 11后便改为/linkerconfig/ld.config.txt

                static const char* const kLdConfigArchFilePath = "/system/etc/ld.config." ABI_STRING ".txt";
                static const char* const kLdConfigFilePath = "/system/etc/ld.config.txt";
                static const char* const kLdConfigVndkLiteFilePath = "/system/etc/ld.config.vndk_lite.txt";
                static const char* const kLdGeneratedConfigFilePath = "/linkerconfig/ld.config.txt";
                static std::string get_ld_config_file_path(const char* executable_path) {
                #ifdef USE_LD_CONFIG_FILE
                  // This is a debugging/testing only feature. Must not be available on
                  // production builds.
                  const char* ld_config_file_env = getenv("LD_CONFIG_FILE");
                  if (ld_config_file_env != nullptr && file_exists(ld_config_file_env)) {
                    return ld_config_file_env;
                  }
                #endif
                  std::string path = get_ld_config_file_apex_path(executable_path);
                  if (!path.empty()) {
                    if (file_exists(path.c_str())) {
                      return path;
                    }
                    DL_WARN("Warning: couldn't read config file \"%s\" for \"%s\"",
                            path.c_str(), executable_path);
                  }
                  path = kLdConfigArchFilePath;
                  if (file_exists(path.c_str())) {
                    return path;
                  }
                  if (file_exists(kLdGeneratedConfigFilePath)) {
                    return kLdGeneratedConfigFilePath;
                  }
                  if (is_linker_config_expected(executable_path)) {
                    DL_WARN("Warning: failed to find generated linker configuration from \"%s\"",
                            kLdGeneratedConfigFilePath);
                  }
                  path = get_ld_config_file_vndk_path();
                  if (file_exists(path.c_str())) {
                    return path;
                  }
                  return kLdConfigFilePath;
                }


                2.2 配置共享库位置

                上一章我们提到了配置文件位置为/linkerconfig/ld.config.txt，

                在Android 11以前ld.config.txt是通过静态文件配置的，而Android 11是改为linkerconfig动态生成

                我们以一个vendor/bin下的native 程序为例，要使用system/lib下的库

                在Android system — Android链接器命名空间（Android 11后）中，我们提到了“目录-区段”映射属性dir.name，指向 [name] 区段所应用到的目录的路径，其实就是baseconfig.cc中定义的dirToSection

                // system/linkerconfig/contents/configuration/baseconfig.cc
                android::linkerconfig::modules::Configuration CreateBaseConfiguration(
                    Context& ctx) {
                  std::vector sections;
                  ctx.SetCurrentLinkerConfigType(LinkerConfigType::Default);
                  // Don't change the order here. The first pattern that matches with the
                  // absolute path of an executable is selected.
                  std::vector dirToSection = {
                      {"/system/bin/", "system"},
                      {"/system/xbin/", "system"},
                      {Var("SYSTEM_EXT") + "/bin/", "system"},
                      // Processes from the product partition will have a separate section if
                      // PRODUCT_PRODUCT_VNDK_VERSION is defined. Otherwise, they are run from
                      // the "system" section.
                      {Var("PRODUCT") + "/bin/", "product"},
                      {"/odm/bin/", "vendor"},
                      {"/vendor/bin/", "vendor"},
                      {"/data/nativetest/odm", "vendor"},
                      {"/data/nativetest64/odm", "vendor"},
                      {"/data/benchmarktest/odm", "vendor"},
                      {"/data/benchmarktest64/odm", "vendor"},
                      {"/data/nativetest/vendor", "vendor"},
                      {"/data/nativetest64/vendor", "vendor"},
                      {"/data/benchmarktest/vendor", "vendor"},
                      {"/data/benchmarktest64/vendor", "vendor"},
                      {"/data/nativetest/unrestricted", "unrestricted"},
                      {"/data/nativetest64/unrestricted", "unrestricted"},
                      // Create isolated namespace for development purpose.
                      // This isolates binary from the system so binaries and libraries from
                      // this location can be separated from system libraries.
                      {"/data/local/tmp/isolated", "isolated"},
                      // Create directories under shell-writable /data/local/tests for
                      // each namespace in order to run tests.
                      {"/data/local/tests/product", "product"},
                      {"/data/local/tests/system", "system"},
                      {"/data/local/tests/unrestricted", "unrestricted"},
                      {"/data/local/tests/vendor", "vendor"},
                      // TODO(b/123864775): Ensure tests are run from one of the subdirectories
                      // above.  Then clean this up.
                      {"/data/local/tmp", "unrestricted"},
                      {"/postinstall", "postinstall"},
                      // Fallback entry to provide APEX namespace lookups for binaries anywhere
                      // else. This must be last.
                      {"/data", "system"},
                      // TODO(b/168556887): Remove this when we have a dedicated section for
                      // binaries in APKs
                      {Var("PRODUCT") + "/app/", "system"},
                  };
                  sections.emplace_back(BuildSystemSection(ctx));
                  if (ctx.IsVndkAvailable()) {
                    sections.emplace_back(BuildVendorSection(ctx));
                    if (android::linkerconfig::modules::IsProductVndkVersionDefined()) {
                      sections.emplace_back(BuildProductSection(ctx));
                    } else {
                      RedirectSection(dirToSection, "product", "system");
                    }
                  } else {
                    RemoveSection(dirToSection, "product");
                    RemoveSection(dirToSection, "vendor");
                  }
                  sections.emplace_back(BuildUnrestrictedSection(ctx));
                  sections.emplace_back(BuildPostInstallSection(ctx));
                  sections.emplace_back(BuildIsolatedSection(ctx));
                  return android::linkerconfig::modules::Configuration(std::move(sections),
                        dirToSection);
                }


                因为我们是vendor/bin下面的程序，所以可以看出来我们是vendor section，因此我们看BuildVendorSection即可。

                // system/linkerconfig/contents/section/vendor.cc
                Section BuildVendorSection(Context& ctx) {
                  ctx.SetCurrentSection(SectionType::Vendor);
                  std::vector namespaces;
                  namespaces.emplace_back(BuildVendorDefaultNamespace(ctx));
                  namespaces.emplace_back(BuildVndkNamespace(ctx, VndkUserPartition::Vendor));
                  namespaces.emplace_back(BuildSystemNamespace(ctx));
                  namespaces.emplace_back(BuildRsNamespace(ctx));
                  if (android::linkerconfig::modules::IsVndkInSystemNamespace()) {
                    namespaces.emplace_back(BuildVndkInSystemNamespace(ctx));
                  }
                  std::set visible_apexes;
                  // APEXes with public libs should be visible
                  for (const auto& apex : ctx.GetApexModules()) {
                    if (apex.public_libs.size() > 0) {
                      visible_apexes.insert(apex.name);
                    }
                  }
                  android::linkerconfig::modules::LibProviders libs_providers = {};
                  if (ctx.IsVndkAvailable()) {
                    libs_providers[":vndk"] = android::linkerconfig::modules::LibProvider{
                        "vndk",
                        std::bind(BuildVndkNamespace, ctx, VndkUserPartition::Vendor),
                        {Var("VNDK_SAMEPROCESS_LIBRARIES_VENDOR"),
                         Var("VNDK_CORE_LIBRARIES_VENDOR")},
                    };
                  }
                  return BuildSection(
                      ctx, "vendor", std::move(namespaces), visible_apexes, libs_providers);
                }


                我们可以看到最后调用了BuildSection，在其中调用了AddStandardSystemLinks 添加system的共享库

                // system/linkerconfig/contents/section/sectionbuilder.cc
                Section BuildSection(const Context& ctx, const std::string& name,
                                     std::vector&& namespaces,
                                     const std::set& visible_apexes,
                                     const LibProviders& providers) {
                  // add additional visible APEX namespaces
                  for (const auto& apex : ctx.GetApexModules()) {
                    if (visible_apexes.find(apex.name) == visible_apexes.end() &&
                        !apex.visible) {
                      continue;
                    }
                    if (auto it = std::find_if(
                            namespaces.begin(),
                            namespaces.end(),
                            [&apex](auto& ns) { return ns.GetName() == apex.namespace_name; });
                        it == namespaces.end()) {
                      auto ns = ctx.BuildApexNamespace(apex, true);
                      namespaces.push_back(std::move(ns));
                    } else {
                      // override "visible" when the apex is already created
                      it->SetVisible(true);
                    }
                  }
                  // resolve provide/require constraints
                  Section section(std::move(name), std::move(namespaces));
                  if (auto res = section.Resolve(ctx, providers); !res.ok()) {
                    LOG(ERROR)
                const std::vector
                    "libc.so",
                    "libdl.so",
                    "libdl_android.so",
                    "libm.so",
                };
                }  // namespace
                namespace android {
                namespace linkerconfig {
                namespace contents {
                using android::linkerconfig::modules::Namespace;
                using android::linkerconfig::modules::Section;
                void AddStandardSystemLinks(const Context& ctx, Section* section) {
                  const bool debuggable = android::base::GetBoolProperty("ro.debuggable", false);
                  const std::string system_ns_name = ctx.GetSystemNamespaceName();
                  const bool is_section_vndk_enabled = ctx.IsSectionVndkEnabled();
                  section-ForEachNamespaces([&](Namespace& ns) {
                    if (ns.GetName() != system_ns_name) {
                      ns.GetLink(system_ns_name).AddSharedLib(kBionicLibs);
                      if (!is_section_vndk_enabled || ns.GetName() != "default") {
                        // TODO(b/185199923) remove the default value
                        ns.GetLink(system_ns_name)
                            .AddSharedLib(Var("SANITIZER_RUNTIME_LIBRARIES", ""));
                      }
                      if (debuggable) {
                        // Library on the system image that can be dlopened for debugging purposes.
                        ns.GetLink(system_ns_name).AddSharedLib("libfdtrack.so");
                      }
                    }
                  });
                }
                }  // namespace contents
                }  // namespace linkerconfig
                }  // namespace android
